PUNKTAL NET Probe & Tone Tracer (P/N: TCT-680)
Ask for quote
Out of stock
Sold by
Maxway Technologies Sdn. Bhd.
Description
Type of tester: LAN wiring / conductor detector
Signal frequency: 500...781Hz (high state), 446...657Hz (low state)
Power supply: 2 batteries 9V 6F22
Kind of display used: 3 LED (transmitter), 4 LED (receiver)
Detection: cable and wire continuity, place of cable failure, cables in walls
Transmitter weight: 86g
Receiver weight: 120g
Protection: anti-overvoltage 24VAC/48VDC
Receiver sensitivity: 30dB
Measuring instrument features:
identifies conductor in group of conductors and identifies cable terminations
identifies state of operating telephone line
possibility of headphones connection
checks correctness of telephone line connections
indication
acoustic indicator
voltage supply for inactive telephone line
low battery indicator
Standard equipment:
2 replaceable tips for probe
soft cover
Interface:
RJ12, RJ45 ( transmitter)
RJ45, Jack (receiver)
Additional information
Gross weight: 0.36 kg
Guarantee (months): 12
Signal frequency: 500...781Hz (high state), 446...657Hz (low state)
Power supply: 2 batteries 9V 6F22
Kind of display used: 3 LED (transmitter), 4 LED (receiver)
Detection: cable and wire continuity, place of cable failure, cables in walls
Transmitter weight: 86g
Receiver weight: 120g
Protection: anti-overvoltage 24VAC/48VDC
Receiver sensitivity: 30dB
Measuring instrument features:
identifies conductor in group of conductors and identifies cable terminations
identifies state of operating telephone line
possibility of headphones connection
checks correctness of telephone line connections
indication
acoustic indicator
voltage supply for inactive telephone line
low battery indicator
Standard equipment:
2 replaceable tips for probe
soft cover
Interface:
RJ12, RJ45 ( transmitter)
RJ45, Jack (receiver)
Additional information
Gross weight: 0.36 kg
Guarantee (months): 12
